Thermostatic Steam Trap
SHT16 Thermostatic Bimetallic Steam Trap
Category: Thermostatic Steam Trap
Technical specification
- GB/T12250-2005 “Steam Trap Terminology Marking Structure Length”
- GB/T22654-2008 “Technical Conditions for Steam Traps”
- GB/T12251-2005 “Test Method for Steam Traps”
- ISO 6948 Automatic steam traps production and performance characteristic tests
Application:
Hot oil system, steam system, hot and cold water system etc.
Advantage
1. The valve body and valve cover are all made of forged steel..
2. The valve disc and valve seat are made of martensitic stainless steel. After heat treatment and aging treatment, they are not denatured and wear-resistant under high temperature and high pressure, which improves the service life of the trap.
3. Imported bimetallic sheet to ensure precise temperature control.
4. The closing system adopts high-precision plane sealing structure.
5.Built-in filter makes the trap work in a clean environment.
6.The back pressure rate is as high as 50% or more.
SKT16 Thermostatic Capsule Steam Trap
Technical specification
- GB/T12250-2005 “Steam Trap Terminology Marking Structure Length”
- GB/T22654-2008 “Technical Conditions for Steam Traps”
- GB/T12251-2005 “Test Method for Steam Traps”
- ISO 6948 Automatic steam traps production and performance characteristic tests
Inverted Bucket Steam Trap
SBT20 Inverted Bucket Steam Trap
Lever Float Ball Steam Trap
SFT50 Lever Float Ball Steam Trap
Sft10 Lever Float Ball Steam Trap
SFT30 Lever Float Ball Steam Trap
Free Float Ball Steam Trap
Free Float Ball Steam Trap
Technical specification
- GB/T12250-2005 “Steam Trap Terminology Marking Structure Length”
- GB/T22654-2008 “Technical Conditions for Steam Traps”
- GB/T12251-2005 “Test Method for Steam Traps”
- ISO 6948 Automatic steam traps
Production and performance characteristic tests
Application
Hot oil system, steam system, hot and cold water system etc.
Advantage
- Stable discharge of water with large amount, small rate of steam leakage, high rate of back pressure.
- The main part hollow floating ball of steel is finely ground in the trap.
- The structure of stainless steel provide the ability of anti-corruption and longer service life.
Pump Trap
PT20 Pump Trap
Technical specification
- GB/T12250-2005 “Steam Trap Terminology Marking Structure Length”
- GB/T22654-2008 “Technical Conditions for Steam Traps”
- GB/T12251-2005 “Test Method for Steam Traps”
- ISO 6948 Automatic steam traps production and performance characteristic tests
Application
Hot oil system, steam system, hot and cold water system etc.
Advantage
- Non electric drive, driven by steam or compressed air, explosion-proof and safe, and can be used in any environment.
- Compact structure, without any requirements for installation, even in the open field, it will not affect its normal operation.
- Automatic control, the size of the water output is determined by the water inflow. When the amount of condensate increases, the working frequency increases, when it decreases, the working frequency decreases, and the work stops without condensate.
- No cavitation work, which completely overcomes the cavitation defect of electric pump.
- All stainless steel internals and special materials ensure performance and service life.
Thermodynamic Steam Trap
STD80 Thermodynamic Steam Trap
STD01T Thermodynamic Steam Trap
STD16 Thermodynamic Steam Trap
Technical specification
- GB/T12250-2005 “Steam Trap Terminology Marking Structure Length”
- GB/T22654-2008 “Technical Conditions for Steam Traps”
- GB/T12251-2005 “Test Method for Steam Traps”
- ISO 6948 Automatic steam traps production and performance characteristic tests
STD42 Thermodynamic Steam Trap
Application
Hot oil system, steam system, hot and cold water system etc.
Advantage
- The valve body and valve cover are all made of forged steel.
- The valve disc and valve seat are made of martensitic stainless steel. After heat treatment and aging treatment, they are not denatured and wear-resistant under high temperature and high pressure, which improves the service life of the trap.
- Stainless steel insulation cover to isolate and slow down heat loss and eliminate the phenomenon of trap air blowing.
- The fluid channel of the internal structure is designed strictly according to Bernoulli’s equation, and the structure is reasonable.
- Built-in filter makes the trap work in a clean environment.
- The back pressure rate is as high as 80% or more.
- To exclude low temperature traps with large subcooling degree, it needs to be customized.
